ECG Module
Witleaf ECG Module integrates the core technologies including wSmartHeart® and iRealRESP®.Start by learning about the range of solutions that may apply to your medical device in our clinical applications section below. View a list of available OEM Modules to choose which technology will meet your medical device needs. Witleaf's ECG Module solution can provided:
> Selection guide supported;
> Integrated tools and technical support;
> Certificated support and standard test report;
> Clinical trial data and report;
> Continuous progress of Algorithm database;
> Fast response for technical support.
> Integrated tools and technical support;
> Certificated support and standard test report;
> Clinical trial data and report;
> Continuous progress of Algorithm database;
> Fast response for technical support.
Table1 ECG Module Select Guide
Model
Electrical Characteristics
Measured parameter
Applicability people
Recommended applications
（M101）
DC12V
2*TEMP、RESP、HR、3/5 ECG
Adult/Pediatric/Neonate
Bedside & General Care
Surgical Care
Intensive Care
Surgical Care
Intensive Care
（M101-C）
DC12V
3 ECG
Adult/Pediatric/Neonate
Bedside & General Care
Surgical Care
Intensive Care
Surgical Care
Intensive Care
（M108）
DC12V
12 ECG
Adult/Pediatric/Neonate
12 leads ECG machine
Model：
（M101）
Electrical Characteristics：
DC12V
Measured parameter：
2*TEMP、RESP、HR、3/5 ECG
Applicability people：
Adult/Pediatric/Neonate
Recommended applications：
Bedside & General Care Surgical Care Intensive Care
Model：
（M101-C）
Electrical Characteristics：
DC12V
Measured parameter：
3 ECG
Applicability people：
Adult/Pediatric/Neonate
Recommended applications：
Bedside & General Care Surgical Care Intensive Care
Model：
（M108）
Electrical Characteristics：
DC12V
Measured parameter：
12 ECG
Applicability people：
Adult/Pediatric/Neonate
Recommended applications：
12 leads ECG machine
wSmartHeart® Technology
wSmartHeart® intelligent ECG detection technology integrates ECG signal quality detection technology, intelligent switching analysis lead technology, ECG signal abnormal fast recovery technology.
tall T wave recognition, and interference elimination technology to ensure the accuracy of heart rate calculation and arrhythmia analysis. Even under interference, the accuracy of identification can still be guaranteed.
iRealRESP® Technology
iRealRESP® breathing technology is a type of respiratory detection technology with good sensitivity, reaching 0.3 ohms. It also equipped with a precise respiratory rate calculation algorithm, anti-cardiac interference algorithms and anti-motion drift algorithms to ensure the stability of respiratory waveforms and the reliability of respiratory rate calculation.
Since its release, through continuously expanding clinical applications, it has had good adaptability in emergency and critical care, as well as bedside monitoring.
