Technical Specifications
SPECIFICATIONS
VALUES
Parameters
3/5-lead ECG、RESP、2*TEMP、HR
Physical Dimensions
125mm×90mm×13.6mm
Voltage
DC 12V±5%
Power Consumption
≤3W (typical, at input voltage 12V±5%)
Communication Protocol
5V TTL-level UART interface
Operating Conditions
0°C to 70°C (32°F to 158°F)，5%-95% non-condensing humidity
Storage Conditions
-40°C to 70°C (-40°F to +158°F)，5%-95% non-condensing humidity
Advantage Technologies
Multi-Lead ECG Synchronization: Enhances heart rate and arrhythmia detection accuracy
Verified against internationally authoritative databases in compliance with EC57 standards, including MIT, AHA, CSE, NST, CU, QTDB, and VFDB
Fast R-wave detection with recognition latency ≤20 ms
Advanced ECG Filtering: Template matching, tall T-wave suppression, and baseline drift cancellation
