Technical Specifications
SPECIFICATIONS
VALUES
Parameters
EtCO2、FICO2、Realtime Capnography
Physical Dimensions
62mm×51mm×25.5mm
Voltage
DC 5V±5%
Extraction Flow
50mL/min
Power Consumption
≤ 0.7W ( typical value, input voltage 5V ± 5 % ). Maximum instantaneous power consumption 2.5 W )
Communication Protocol
Rs232, TTL level ( 3.3V ), UART interface
Operating Conditions
0°C to 50°C (32°F to 122°F)，5%-95% non-condensing humidity
Storage Conditions
-20°C to 70°C (-4°F to +158°F)，5%-95% non-condensing humidity
Advantage Technologies
Plug-and-play design with wide operating temperature range
Compact design for portable applications
Supports WITLEAF communication protocol and optional compatible protocols
Dedicated consumables designed to meet ISO 18562-1/-2/-3/-4 biocompatibility requirements
Complies with IEC 60601-1-2:2014/AMD1:2020 for EMC, with radiated immunity meeting Class B requirements
