Technical Specifications
SPECIFICATIONS
VALUES
Parameters
NIBP，3-lead ECG，HR
Physical Dimensions
73mm×53mm×16mm
Voltage
DC 5V±5%
Power Consumption
≤3W (typical, at input voltage 5V±5%)
Communication Protocol
5V TTL-level UART interface
Operating Conditions
0°C to 70°C (32°F to 158°F)，5%-95% non-condensing humidity
Storage Conditions
-40°C to 70°C (-40°F to +158°F)，5%-95% non-condensing humidity
Advantage Technologies
Motion-Resistant NIBP Technology: multi-feature matching and frequency-domain interference rejection
Multi-Mode NIBP Measurement: Step deflation (AAMI-standard) and Inflation-Phase Monitoring
Verified against internationally authoritative databases in compliance with EC57 standards, including MIT, AHA, CSE, NST, CU, QTDB, and VFDB
Advanced ECG Filtering: Template matching, tall T-wave suppression, and baseline drift cancellation
