Technical Specifications
SPECIFICATIONS
VALUES
Parameters
SYS MAP DIA PR
Physical Dimensions
76mm×53mm×16mm
Voltage
DC 5V±5%
Power Consumption
≤3W (typical, at input voltage 5V±5%)
Communication Protocol
5V TTL-level UART interface
Operating Conditions
0°C to 70°C (32°F to 158°F)，5%-95% non-condensing humidity
Storage Conditions
-40°C to 70°C (-40°F to +158°F)，5%-95% non-condensing humidity
Advantage Technologies
Motion-Resistant NIBP Technology: multi-feature matching and frequency-domain interference rejection
Multi-Mode NIBP Measurement: Step deflation (AAMI-standard) and Inflation-Phase Monitoring
Fast NIBP measurement: ≤25 seconds for normal subjects
Dual overvoltage protection for fail-safe operation
Self-established NIBP database covering hypertensive, elderly, neonatal and pregnant populations
OEM Customized Solutions
