Technical Specifications
SPECIFICATIONS
VALUES
Parameters
3/5-lead ECG、SPO2、NIBP、RESP、2*TEMP、PR、HR
Physical Dimensions
140mm×85mm×25mm
Voltage
DC 12V±5%
Power Consumption
≤6W (typical, at input voltage 12V±5%)
Communication Protocol
5V TTL-level UART interface
Operating Conditions
0°C to 70°C (32°F to 158°F)，5%-95% non-condensing humidity
Storage Conditions
-40°C to 70°C (-40°F to +158°F)，5%-95% non-condensing humidity
Advantage Technologies
Highly Integrated Multi-Parameter Modular Design
Veterinary-Specific Algorithm
Dual-Domain SpO₂: Fuses time and frequency domains to suppress motion artifacts
Motion-Resistant NIBP Technology: multi-feature matching and frequency-domain interference rejection
Anti-Interference and Weak Signal Detection Capabilities
Multi-Lead ECG Synchronization: Enhances heart rate and arrhythmia detection accuracy
Advanced ECG Filtering: Template matching, tall T-wave suppression, and baseline drift cancellation
OEM Customized Solutions
